Model# F71C663BB0
The image and part list below are associated with the component: 06 - MOTOR DETAILS:
For Support or Ordering By Phone,
Call (800) 816-0715 Mon–Fri 8 am to 9 pm, Sat 8 am to 3 pm EST
| Description | Part# | Substitution# | Diagram Reference | ETA | ||
|---|---|---|---|---|---|---|
|
SCREW 10-32 HEXAGONAL | 5300806353 | 1 | 5 days | ||
|
LOWER IMPELLER | 5300809909 | 10 | 5 days | ||
|
SEAL KIT | 5300803903 | 11 | 5 days | ||
|
PUMP HOUSING | 5300809591 | 5303943122 | 13 | 5 days | |
|
SCREW-10 X 1``(3) | 5300807268 | 14 | 5 days | ||
|
HOSE CLAMP | 5300808186 | 5364154013 | 15 | 5 days | |
|
PUMP CLAMP | 5300809590 | 16 | 5 days | ||
|
WASHER - HEATER (2) | 5300809587 | 17 | 11 days | ||
|
INSULATING WASHER | 154064901 | 18 | 5 days | ||
|
HEATER NUT (2) | 154106201 | 154106202 | 19 | 5 days | |
|
HEATER BRACKET (2) | 5300809585 | 2 | 11 days | ||
|
WATERSHIELD ASSY | 5300809366 | 20 | 5 days | ||
|
MOTOR | 5300809984 | 5303943142 | 21 | 5 days | |
|
SCREW-MOTOR MTG (4) | 5300809022 | 154200901 | 22 | 11 days | |
|
TOOL | 5300803923 | 23 | 5 days | ||
|
FILTER HOUSING ASSY | 154158301 | 5303943124 | 24 | 5 days | |
|
SCREW 10 X 1 3/4`` | 5300807359 | 5304471401 | 25 | 5 days | |
|
LOWER SPRAY ARM ASSY | 154156602 | 26 | 5 days | ||
|
SPRAY ARM SHIELD (2) | 5300809938 | 27 | 5 days | ||
|
SPRAY ARM NUT | 154190401 | 28 | 5 days | ||
|
O-RING | 5300809015 | 29 | 5 days | ||
|
SCREW-HEATER BRACKET(2) (NON-ILLUSTRATED) | 5300810094 | 2A | 11 days | ||
|
HEATER | 5300809584 | 3 | 5 days | ||
|
O-RING | 5300809016 | 30 | 5 days | ||
|
SCREW | 5300809012 | 31 | 11 days | ||
|
CHECK VALVE | 5300809937 | 32 | 5 days | ||
|
DELIVERY TUBE | 154119301 | 33 | 11 days | ||
|
UPPER SPRAY ARM | 154119401 | 34 | 11 days | ||
|
PLATE-UPPER SPRAY ARM MOUNTING | 154126401 | 35 | 11 days | ||
|
UPPER IMPELLER | 5300809918 | 4 | 5 days | ||
|
MACERATOR | 5300809920 | 5 | 5 days | ||
|
SPACER PLATE | 5300809921 | 6 | 5 days | ||
|
PUMP PLATE | 5300809006 | 7 | 11 days | ||
|
PUMP GASKET | 5300809007 | 8 | - |
|
|
|
O-RING | 5300806521 | 9 | 5 days |
